FLEX-HONE®
How easy is it to use?
It is very easy to use. The abrasive globules each have independent suspension that assures the FLEX-HONE to be self-centering, self-aligning to the bore and self-compensating for wear. No time-consuming training or set up is needed
What’s the difference between a FLEX-HONE and Ball Hone?
There is no difference. The FLEX-HONE® and Ball Hone® are both trademarked names for our tools. We market the tool under the name FLEX-HONE, but a common name is Ball Hone. Colloquially, some people also refer to the tool as a dingleberry hone, grape hone, bead hone, bottle brush hone, glaze buster/breaker hone, or flexible hone, but we do our best to dissuade the usage of those terms and to promote FLEX-HONE. In any case, if it says BRM, you've got the best.
What RPM do spin it at?
The RPM will vary with the size of the tool and will range from 1200 to 60 RPM. The smaller the hone, the faster the speed. For a 1" tool, for instance you will want to be at around 800 RPM, for a 3" tool, you should be near 700 RPM, for a 6" tool, you'll be nearer to 450 RPM and so on. These are just guidelines and optimal performance for each specific application will be found with a bit of experimentation and testing.The FLEX-HONE tool is a low RPM tool. Specific RPM is dependent on the diameter of the tool and the application. General speed ranges are given but, again, machine trials are required to verify the parameters.
Hone Dia. RPM
19" to 36" 60 to 120 RPM
12" to 18" 80 to 350 RPM
8" to 12" 300 to 500 RPM
4" to 8" 400 to 700 RPM
2" to 4" 600 to 800 RPM
1" to 2" 700 to 900 RPM
4mm to 1" 800 to 1200 RPM
How do I know what grit/abrasive type I have?
The grit and abrasive type is identified by two key markings, one on the stem and one on the tip. The stem markings identify the abrasive type and the tip markings identify the abrasive grit. Please see the FLEX-HONE Abrasive/Grit charts for details.
Will it remove too much material?
No. The FLEX-HONE tool is a surface finishing tool, not a material removal tool. We are reducing the rough peaks of a surfaces microstructure and typically we only remove a small amount of material.
Why is the tool I got larger than what I ordered?
Because the tool needs to be slightly oversized to function properly. The tools should always be ordered to the true ID of the bore to be worked, and then they are manufactured with the correct oversize.
I have a taper or a stepped diameter hole. What can I do?
Contact us or review our Custom Brush product section and fill out the form. We can design and manufacture tapered FLEX-HONE tools and stepped or multi-diameter FLEX-HONE tools in any of our abrasive types and grits.
How long does it last?
This is a very frequently asked question and the hardest to answer as there is no true answer. For many end users, one FLEX-HONE tool will last forever. For our high volume OEM customers, however, this is a bigger issue. The life of the tool will vary due to the following: Tool diameter, grit size, abrasive type, beginning roughness of the work piece, desired roughness of the work piece, stroke rate, rpm, material type, lubricant used, and many more. If you need more tool life for an ongoing application, please contact our technical staff to help you determine key points that may improve the longevity or number of parts worked per tool.
company
How do I order?
You can place an order by telephone,fax or direct from our website. PH: (323)261-2193 FAX: (323)268-6587
Where do you manufacture?
Brush Research is located in Los Angeles, CA.
Do I order from the factory or a distributor?
It is your choice. If you do buy direct from the company, please use the company website to process your order with a credit card.
How do I purchase product if I am located outside of the United States?
Brush Research works with a large network of international distributors. Please contact the office so we can refer you to a distributor located near you that can support.
Do you ship UPS or FedEx?
We offer both methods for your convenience.
other
When should I use a Dot Style Nampower disc brush?
Dot style discs are used for general purpose edge deburring and surface finishing applications. The Dot style is an economical choice for light deburring applications. Dot style brushes provide greater flexibility and allow entry into small holes and spaces with ease.
When should I use a Turbine Style Nampower disc brush?
Dot style discs are ideal for medium and heavy deburring applications. The Turbine style brush has a high density fill that is ideal for short cycle times and long tool life.
When using a disc brush, what trim length do I need?
Trim length selection is about flexibility versus aggressiveness. Longer trim lengths are less aggressive and more flexible while shorter trim lengths are less flexible and more aggressive. Burr size, part shape and conformity, radius requirements and final finish requirements are all factors affecting trim length selection.
When using a disc brush, what grit should I use?
Grit selection is highly dependent on the starting surface finish and the amount of material refinement required. The general rule of thumb is to choose the coarsest grit possible that will still yield the required surface finish. A fine grit tool used on a coarse starting finish will have less effect on the overall finish improvement as a coarse grit tool followed by a finer grit tool. Coarse grits are recommended for use on heavier burrs or where a fine surface finish is not required.
